Texas Instruments SN74ACT14DRE4

Part No.:: SN74ACT14DRE4

Manufacturer:: Texas Instruments

Package:: 14-SOIC

Datasheet:: SN74ACT14DRE4.pdf

Description:: IC INV SCHMITT 6CH 1-IN 14SOIC

In Stock:: 3774

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN74ACT14DRE4 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
74ACT
ProductStatus:
Discontinued at Mosen
LogicType:
Inverter
NumberofCircuits:
6
NumberofInputs:
1
Features:
Schmitt Trigger
Voltage-Supply:
4.5V ~ 5.5V
Current-Quiescent(Max):
2 µA
Current-OutputHighLow:
24mA, 24mA
LogicLevel-Low:
0.5V ~ 1.4V
LogicLevel-High:
1.2V ~ 2.1V
MaxPropagationDelay@VMaxCL:
11.5ns @ 5V, 50pF
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount

SN74ACT14DRE4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including SN74ACT14DRE4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for SN74ACT14DRE4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

SN74ACT14DRE4 information

Views：

SN74ACT14DRE4 Typical application Circuitry

SN74ACT14DRE4

The SN74ACT14DRE4 is a hex schmitt-trigger inverter chip, commonly used in digital electronic circuits. Here is a thorough examination of its functions, uses, and a particular circuit implementation.

Functionality of SN74ACT14DRE4:

- Hex Schmitt-Trigger Inverters: The SN74ACT14DRE4 consists of six independent Schmitt-trigger inverters. It is utilized to convert analog signals to digital signals, especially when hysteresis and noise immunity are needed.

Application Scenarios:

- Waveform Shaping: Often used in applications for transforming irregular waveforms into square waves.

- Debouncing Switches: Ideal for cleaning noisy signals from mechanical switches.

Important Elements and Characteristics:

- Voltage Range: Has a broad voltage range of operation.

- Hysteresis: Provides excellent noise immunity due to its inherent hysteresis.

- Speed: Fast switching speeds.

Circuit Implementation: Debouncing a Mechanical Switch

- Connect Power Supply: Attach GND (pin 7) to ground and VCC (usually pin 14) to a 5V power source.

- Input Connection: Connect a mechanical switch to one input of the inverter (for example, pin 1). The other side of the switch should be connected to the ground.

- Pull-up Resistor: Connect a pull-up resistor (10KΩ) between the VCC and the input pin to ensure a default high state when the switch is open.

- Output Connection: The output (for example, from pin 2) can be connected to a digital input of a microcontroller.

- Bypass Capacitor: Place a 0.1 μF capacitor close to the VCC pin for power supply stability.

Design Considerations:

- Power Supply Stability: Ensure a stable power supply to avoid false triggering.

- Input Noise: Be aware of the noise level in the environment as it affects the performance.

- Load Capacitance: The capacitive load on the output should be within the specified limits to prevent malfunction.

Incorporating the SN74ACT14DRE4 in a debounce circuit helps in achieving stable digital signals from mechanical switches, making it a robust choice for digital systems requiring clean input signals.

Remember, each application scenario might require different pin configurations and additional components, so it's crucial to understand the specific requirements of your circuit.
