Texas Instruments SN7407DR

Part No.:: SN7407DR

Manufacturer:: Texas Instruments

Package:: 14-SOIC (0.154, 3.90mm Width)

Datasheet:: SN7407DR.pdf

Description:: IC BUF NON-INVERT 5.25V 14SOIC

In Stock:: 2754

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN7407DR Specifications

Package/Case:
14-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
7400
ProductStatus:
Active
LogicType:
Buffer, Non-Inverting
NumberofElements:
6
NumberofBitsperElement:
1
InputType:
-
OutputType:
Open Collector
Current-OutputHighLow:
-, 40mA
Voltage-Supply:
4.75V ~ 5.25V
OperatingTemperature:
0°C ~ 70°C (TA)
MountingType:
Surface Mount

SN7407DR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including SN7407DR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for SN7407DR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
