Texas Instruments SN65LVDS2DBVR

Part No.:: SN65LVDS2DBVR

Manufacturer:: Texas Instruments

Package:: SC-74A, SOT-753

Datasheet:: SN65LVDS2DBVR.pdf

Description:: IC RECEIVER 0/1 SOT23-5

In Stock:: 2716

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN65LVDS2DBVR Specifications

Package/Case:
SC-74A, SOT-753
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
65LVDS
ProductStatus:
Active
Type:
Receiver
Protocol:
LVDS
NumberofDrivers/Receivers:
0/1
Duplex:
-
ReceiverHysteresis:
-
DataRate:
400Mbps
Voltage-Supply:
2.4V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
