Texas Instruments SN65LVDS105PWRG4

Part No.:: SN65LVDS105PWRG4

Manufacturer:: Texas Instruments

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:: SN65LVDS105PWRG4.pdf

Description:: IC MULTIPLEXER 1CH 16TSSOP

In Stock:: 2251

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN65LVDS105PWRG4 Specifications

Package/Case:
16-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Discontinued at Mosen
Type:
Buffer, Multiplexer
Applications:
-
Input:
LVTTL
Output:
LVDS
DataRate(Max):
400Mbps
NumberofChannels:
1 x 1:4
DelayTime:
2.2ns
SignalConditioning:
-
Capacitance-Input:
3 pF
Voltage-Supply:
3V ~ 3.6V
Current-Supply:
23mA
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
