Texas Instruments SN65HVD230QDRG4Q1

Part No.:: SN65HVD230QDRG4Q1

Manufacturer:: Texas Instruments

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: SN65HVD230QDRG4Q1.pdf

Description:: IC TRANSCEIVER HALF 1/1 8SOIC

In Stock:: 2459

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SN65HVD230QDRG4Q1 Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
Automotive, AEC-Q100
ProductStatus:
Active
Type:
Transceiver
Protocol:
CANbus
NumberofDrivers/Receivers:
1/1
Duplex:
Half
ReceiverHysteresis:
100 mV
DataRate:
1Mbps
Voltage-Supply:
3V ~ 3.6V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
