Texas Instruments SM320F28335PTPS

Part No.:: SM320F28335PTPS

Manufacturer:: Texas Instruments

Package:: 176-LQFP Exposed Pad

Datasheet:: SM320F28335PTPS.pdf

Description:: IC MCU 32BIT 512KB FLSH 176HLQFP

In Stock:: 152

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SM320F28335PTPS Specifications

Package/Case:
176-LQFP Exposed Pad
Packaging:
Tray
Series:
C2000™ C28x Delfino™
RoHS:
RoHS
Speed:
150MHz
RAM Size:
34K x 16
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, I²C, McBSP, SCI, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
88
Core Processor:
C28x
Data Converters:
A/D 16x12b
Oscillator Type:
Internal
Program Memory Size:
512KB (256K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-55°C ~ 150°C (TA)
