Vishay Semiconductor Opto Division SFH6916

Part No.:: SFH6916

Manufacturer:: Vishay Semiconductor Opto Division

Package:: 16-SOIC (0.173, 4.40mm Width)

Datasheet:: SFH6916.pdf

Description:: OPTOISO 3.75KV 4CH TRANS 16-SOP

In Stock:: 3723

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SFH6916 Specifications

Packaging:
Tube
Series:
-
ProductStatus:
Active
NumberofChannels:
4
Voltage-Isolation:
3750Vrms
CurrentTransferRatio(Min):
50% @ 5mA
CurrentTransferRatio(Max):
300% @ 5mA
TurnOn/TurnOffTime(Typ):
5µs, 4µs
Rise/FallTime(Typ):
4µs, 3µs
InputType:
DC
OutputType:
Transistor
Voltage-Output(Max):
70V
Current-Output/Channel:
50mA
Voltage-Forward(Vf)(Typ):
1.15V
Current-DCForward(If)(Max):
50 mA
VceSaturation(Max):
400mV
OperatingTemperature:
-55°C ~ 100°C
MountingType:
Surface Mount
