Murata Electronics SCA100T-D01-6

Part No.:: SCA100T-D01-6

Manufacturer:: Murata Electronics

Package:: 12-SMD Module

Datasheet:: SCA100T-D01-6.pdf

Description:: SENSOR INCLINOMETER 30DEG 12SMD

In Stock:: 3113

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SCA100T-D01-6 Specifications

Packaging:
Tape & Reel (TR)
Series:
SCA100T
ProductStatus:
Obsolete
Axis:
X, Y
MeasuringRange:
±30°
Sensitivity:
4V/g
Bandwidth:
10Hz
VoltageRating:
4.75 V ~ 5.25 V
OutputType:
Digital
Interface:
SPI
