NXP USA Inc. SC28L92A1BS,551

Part No.:: SC28L92A1BS,551

Manufacturer:: NXP USA Inc.

Package:: 48-VFQFN Exposed Pad

Datasheet:: SC28L92A1BS,551.pdf

Description:: IC UART DUAL W/FIFO 48HVQFN

In Stock:: 2805

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SC28L92A1BS,551 Specifications

Package/Case:
48-VFQFN Exposed Pad
Packaging:
Tray
Series:
Impact
ProductStatus:
Obsolete
Features:
Configurable GPIO, Internal Oscillator, Timer/Counter
NumberofChannels:
2, DUART
FIFO's:
16 Byte
Protocol:
-
DataRate(Max):
1Mbps
Voltage-Supply:
3.3V, 5V
WithAutoFlowControl:
Yes
WithIrDAEncoder/Decoder:
-
WithFalseStartBitDetection:
Yes
WithModemControl:
Yes
MountingType:
Surface Mount
