NXP USA Inc. SC28L198A1BE,528

Part No.:: SC28L198A1BE,528

Manufacturer:: NXP USA Inc.

Package:: 100-LQFP

Datasheet:: SC28L198A1BE,528.pdf

Description:: IC UART OCTAL 100LQFP

In Stock:: 2858

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SC28L198A1BE,528 Specifications

Package/Case:
100-LQFP
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
Features:
Internal Oscillator, Timer/Counter
NumberofChannels:
8
FIFO's:
16 Byte
Protocol:
-
DataRate(Max):
-
Voltage-Supply:
3.3V, 5V
WithAutoFlowControl:
Yes
WithIrDAEncoder/Decoder:
-
WithFalseStartBitDetection:
Yes
WithModemControl:
Yes
MountingType:
Surface Mount
