The SC16IS750IBS,151 can be applied in several scenarios:
- Embedded Systems: For microcontrollers without a built-in UART or with insufficient UARTs.
- Industrial Automation: To interface with sensors and control systems.
- Data Logging: Connecting to various sensors for serial data collection.
Key Features:
- UART Interface: Full modem control and hardware/software flow control.
- Programmable Baud Rate: From 50 bps to 5 Mbps.
- Buffers: 64-byte FIFOs for transmission and reception.
- I2C/SPI Interface: Selectable interface for communication.
Circuit Connection Example: UART to I2C Bridge
Overview: This example demonstrates how to connect the SC16IS750IBS,151 to a microcontroller using I2C.
1. VCC and GND: Connect the VCC pin to a 3.3V power supply and the GND pin to ground.
2. I2C Connection: Join the corresponding I2C lines of the microcontroller to SDA (Serial Data) and SCL (Serial Clock).
3. UART Interface: Connect the TX and RX pins of the SC16IS750IBS,151 to the device you want to communicate with.
4. Oscillator: An external crystal oscillator is required for the UART's baud rate. Connect it to the XTAL1 and XTAL2 pins.
5. Interrupt Line (Optional): An interrupt line can be connected to the microcontroller to signal when data is ready.
6. Reset Line: A reset line can be connected to the microcontroller for hardware reset functionality.
7. Programming and Configuration: Use the I2C lines to program and configure the SC16IS750IBS,151 for the desired UART settings.
Design Considerations:
- Power Supply: Ensure a stable 3.3V supply.
- Baud Rate Matching: The baud rate of the UART should match the connected device.
- I2C/SPI Speed: Ensure the microcontroller's I2C/SPI speed is compatible.
- Buffer Management: Manage the FIFO buffers effectively to prevent data overrun.
Using the SC16IS750IBS,151, the designer can effectively add UART capabilities to systems, making it a versatile choice for serial communication enhancement.
