What is the Additional Feature ?

Name: SA555DRE4
Brand: Texas Instruments
SKU: SA555DRE4
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Texas Instruments SA555DRE4

Part No.:: SA555DRE4

Manufacturer:: Texas Instruments

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: SA555DRE4.pdf

Description:: IC OSC SGL TIMER 100KHZ 8-SOIC

In Stock:: 3911

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SA555DRE4 Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Discontinued at Mosen
Type:
555 Type, Timer/Oscillator (Single)
Count:
-
Frequency:
100kHz
Voltage-Supply:
4.5V ~ 16V
Current-Supply:
10 mA
OperatingTemperature:
-40°C ~ 85°C

SA555DRE4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including SA555DRE4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for SA555DRE4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

SA555DRE4 information

Views：

SA555DRE4 Typical application Circuitry

SA555DRE4

A common 555 timer integrated circuit (IC) version used in electronics for a variety of timing and oscillator applications is the SA555DRE4. Its key features include a wide supply voltage range, stable operation over a broad temperature range, and a direct interface with CMOS, NMOS, and TTL. This chip is versatile and can be used in applications like pulse generation, timing delays, tone generation, and as part of more complex circuits like a PWM (Pulse Width Modulation) controller.

Application Scenario: Monostable Operation for Delay Timer

Circuit Connection:

- Pin 1 (Ground): Connect to the ground of the power supply.

- Pin 2 (Trigger): Connect to the negative terminal of a capacitor whose positive terminal is linked to the power supply. A common 555 timer integrated circuit (IC) version used in electronics for a variety of timing and oscillator applications is the SA555DRE4.

- Pin 3 (Output): Connect to the load, which could be a LED or relay.

- Pin 4 (Reset): Tie this pin to VCC to avoid accidental resets; connect to ground for an external reset function.

- Pin 5 (Control Voltage): This pin can be left open or connected to a capacitor (about 0.01 µF) to ground for stability.

- Pin 6 (Threshold): Connect to the same node as Pin 2, forming part of the RC timing circuit.

- Pin 7 (Discharge): Connect to the other side of the resistor in the RC network.

- Pin 8 (VCC): Connect to the positive supply voltage.

Programming Pins for Burning Firmware:

- SA555DRE4 does not require firmware or programming as it is an analog IC.

Design considerations include:

- Supply Voltage: Make sure the voltage is within the operational range of the chip.

- Timing Components: Select the resistor and capacitor values for the desired time delay, considering the formula $ T = 1.1 \times R \times C $.

- Load Characteristics: The output current and voltage should match the requirements of the load.

- Temperature Stability: Use components that offer stability across the operational temperature range.

- Interference and Noise: Include bypass capacitors to reduce noise and interference in the circuit.

In designing with the SA555DRE4, it's important to focus on the precision of the timing components, the power supply stability, and the environmental conditions under which the circuit will operate. Proper layout and grounding techniques are also critical to ensure reliable performance.

SA555DRE4 FAQ

1. How to order SA555DRE4 on icwhale.com?

Currently, icwhale.com only provide peer-to-peer order processing. While you submit the RFQ, our professional agent will contact you with the competitive prices in the global market, and our agent will prompt you to finish the order if you accept our offers.

2. How does icwhale.com guarantee that SA555DRE4 is from the original manufacturer or authorized agents?

We have a professional and experienced quality control team to strictly verify and test the SA555DRE4. All suppliers must pass our qualification reviews before they can publish their products including SA555DRE4 on icwhale.com; we pay more attention to the channels and quality of SA555DRE4 products than any other customer. We strictly implement supplier audits, so you can purchase with confidence.

3. Are the SA555DRE4 price and inventory displayed accurate?

The price and inventory of SA555DRE4 fluctuates frequently and cannot be updated in time, it will be updated periodically within 24 hours. And, our quotation usually expires after 5 days.

4. What forms of payment are accepted?

Wire Transfer, PayPal, Alipay, Wechat, Credit Card, Western Union, MoneyGram, and Escrow are all acceptable.

Warm Tips: Some orders in certain payment forms may require handling fee.

5. How is the shipping arranged?

Customers can choose industry-leading freight companies, including DHL, UPS, FedEx, TNT, and Registered Mail. Shipping insurance is also available.

Once your order has been processed for shipment, our salesperson will send you an email advising you of the shipping status and tracking number.

Warm Tips: It may take up to 24 hours for the carriers to display tracking information. Usually, express delivery takes 3-5 days, and registered mail takes 25-60 days.

6. What is the process for return or replacement of SA555DRE4?

All goods will implement Pre-Shipment Inspection (PSI), selected at random from all batches of your order to do a systematic inspection before arranging the shipment. If there is something wrong with the SA555DRE4 we delivered, we will accept the replacement or return of the SA555DRE4 only when all of the below conditions are fulfilled:

(1)Such as a deficiency in quantity, delivery of wrong items, and apparent external defects (breakage and rust, etc.), and we acknowledge such problems.

(2)We are informed of the defect described above within 90 days after the delivery of SA555DRE4.

(3)The PartNo is unused and only in the original unpacked packaging.

Two processes to return the products:

(1)Inform us within 90 days

(2)Obtain Requesting Return Authorizations
