NXP USA Inc. S9S12P128J0MQK

Part No.:: S9S12P128J0MQK

Manufacturer:: NXP USA Inc.

Package:: 80-QFP

Datasheet:: S9S12P128J0MQK.pdf

Description:: IC MCU 16BIT 128KB FLASH 80QFP

In Stock:: 3206

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

S9S12P128J0MQK Specifications

Package/Case:
80-QFP
Packaging:
Tray
Series:
HCS12
RoHS:
RoHS
Speed:
32MHz
RAM Size:
6K x 8
Core Size:
16-Bit
EEPROM Size:
4K x 8
Part Status:
Active
Peripherals:
LVD, POR, PWM, WDT
Connectivity:
CANbus, SCI, SPI
Mounting Type:
Surface Mount
Number of I/O:
64
Core Processor:
HCS12
Data Converters:
A/D 10x12b
Oscillator Type:
Internal
Program Memory Size:
128KB (128K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TA)
