NXP USA Inc. S912ZVMC64F3WKH

Part No.:: S912ZVMC64F3WKH

Manufacturer:: NXP USA Inc.

Package:: 64-LQFP Exposed Pad

Datasheet:: S912ZVMC64F3WKH.pdf

Description:: IC MCU 16BIT 64KB FLASH 64LQFP

In Stock:: 2742

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

S912ZVMC64F3WKH Specifications

Package/Case:
64-LQFP Exposed Pad
Packaging:
Tray
Series:
S12 MagniV
RoHS:
RoHS
Speed:
50MHz
RAM Size:
4K x 8
Core Size:
16-Bit
EEPROM Size:
512 x 8
Part Status:
Active
Peripherals:
DMA, POR, PWM, WDT
Connectivity:
CANbus, SCI, SPI
Mounting Type:
Surface Mount
Number of I/O:
31
Core Processor:
S12Z
Data Converters:
A/D 9x12b
Oscillator Type:
Internal
Program Memory Size:
64KB (64K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 150°C (TA)
