Cypress Semiconductor Corp S29GL01GP11FFIR10

Part No.:: S29GL01GP11FFIR10

Manufacturer:: Cypress Semiconductor Corp

Package:: 64-LBGA

Datasheet:: S29GL01GP11FFIR10.pdf

Description:: IC FLASH 1GBIT PARALLEL 64BGA

In Stock:: 2908

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

S29GL01GP11FFIR10 Specifications

Package/Case:
64-LBGA
Packaging:
Tray
Series:
GL-P
ProductStatus:
Obsolete
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NOR
MemorySize:
1Gb (128M x 8)
MemoryInterface:
Parallel
ClockFrequency:
-
WriteCycleTime-WordPage:
110ns
AccessTime:
110 ns
Voltage-Supply:
3V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
