Name: S29AL016J70BFI020
Brand: Cypress Semiconductor Corp
SKU: S29AL016J70BFI020
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Cypress Semiconductor Corp S29AL016J70BFI020

Part No.:: S29AL016J70BFI020

Manufacturer:: Cypress Semiconductor Corp

Package:: 48-VFBGA

Datasheet:: S29AL016J70BFI020.pdf

Description:: IC FLASH 16MBIT PARALLEL 48FBGA

In Stock:: 2768

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

S29AL016J70BFI020 Specifications

Package/Case:
48-VFBGA
Packaging:
Tray,Tray
Series:
AL-J
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NOR
MemorySize:
16Mb (2M x 8, 1M x 16)
MemoryInterface:
Parallel
ClockFrequency:
-
WriteCycleTime-WordPage:
70ns
AccessTime:
70 ns
Voltage-Supply:
2.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
