Cypress Semiconductor Corp S26KL512SDABHB020

Part No.:: S26KL512SDABHB020

Manufacturer:: Cypress Semiconductor Corp

Package:: 24-VBGA

Datasheet:

Description:: IC FLASH 512MBIT PARALLEL 24FBGA

In Stock:: 2706

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

S26KL512SDABHB020 Specifications

Package/Case:
24-VBGA
Packaging:
Tray
Series:
Automotive, AEC-Q100, HyperFlash™ KL
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NOR
MemorySize:
512Mb (64M x 8)
MemoryInterface:
Parallel
ClockFrequency:
100 MHz
WriteCycleTime-WordPage:
-
AccessTime:
96 ns
Voltage-Supply:
2.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 105°C (TA)
MountingType:
Surface Mount
