Cypress Semiconductor Corp S25FS512SAGNFI010

Part No.:: S25FS512SAGNFI010

Manufacturer:: Cypress Semiconductor Corp

Package:: 8-WDFN Exposed Pad

Datasheet:: S25FS512SAGNFI010.pdf

Description:: IC FLASH 512MBIT SPI/QUAD 8WSON

In Stock:: 2002

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

S25FS512SAGNFI010 Specifications

Package/Case:
8-WDFN Exposed Pad
Packaging:
Bulk,Tray
Series:
FS-S
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NOR
MemorySize:
512Mb (64M x 8)
MemoryInterface:
SPI - Quad I/O, QPI
ClockFrequency:
133 MHz
WriteCycleTime-WordPage:
-
AccessTime:
-
Voltage-Supply:
1.7V ~ 2V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount

S25FS512SAGNFI010 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including S25FS512SAGNFI010 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for S25FS512SAGNFI010 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

S25FS512SAGNFI010 information

Views：

S25FS512SAGNFI010 Typical application Circuitry

S25FS512SAGNFI010

The S25FS512SAGNFI010 is a Serial NOR Flash memory chip with a 512 Megabit (Mb) storage capacity, designed by Cypress Semiconductor (now part of Infineon Technologies). This chip is part of the FS-S family, tailored for high-performance applications requiring fast read and write capabilities, robust data retention, and high reliability. It supports various Serial Peripheral Interface (SPI) modes, including Single, Dual, Quad, and DDR Quad SPI, enabling flexible and efficient data transfer.

Functionality & Application Scenarios

- Embedded Systems: For storing firmware, operating systems, and application code.

- Automotive Electronics: In ADAS, infotainment systems, and electronic control units for firmware storage.

- Industrial Controls: For program storage, device configuration, and extensive data logging.

- Consumer Electronics: In digital cameras, smartwatches, and other portable devices for firmware and settings storage.

- IoT Devices: Storing firmware updates and operational parameters, especially for OTA update capabilities.

Key Parameters & Features

- 512Mb Storage Capacity: Ample space for complex firmware and data.

- SPI Interface Compatibility: Supports Single, Dual, Quad, and DDR Quad SPI modes for versatile data transfers.

- High-Speed Read and Write: Enhances device performance with quick data access and storage.

- Sector Erase & Program Functions: Facilitates efficient data management and updates.

- Advanced Security Features: Provides secure data storage and protection mechanisms.

Detailed Application Scenario: Firmware Storage in Embedded Systems

Circuit Connection Detail

Integrating the S25FS512SAGNFI010 into an embedded system for firmware storage entails precise circuit configuration for effective performance and reliability.

1. SPI Communication Interface

Interface the S25FS512SAGNFI010's SPI pins with the embedded system's microcontroller. This involves connecting the Serial Clock (SCK), Chip Select (CS), Serial Data Input (SI), and Serial Data Output (SO) for basic SPI functionality. In Quad SPI mode, also connect the IO2 and IO3 pins. Ensuring short, impedance-controlled traces is critical for maintaining signal integrity, especially at high-speed data rates.

2. Power Supply Design

Supply stable power to the S25FS512SAGNFI010 VCC pin and ground the VSS pin. Utilizing decoupling capacitors near these pins is essential to minimize power supply noise, promoting stable operation. It's critical to ensure stable power supply conditions to prevent potential data corruption.

3. Write Protection Mechanism

Utilize the S25FS512SAGNFI010 Write Protect (WP) pin for hardware-based write protection. Dynamically controlling this feature through connection to a GPIO pin on the microcontroller allows for enhanced data security by safeguarding against unintended write or erase operations. Incorporating a pull-up resistor on the WP pin ensures a default state of protection.

4. HOLD Pin Functionality

Employ the HOLD pin to pause communication with the Flash memory. This is particularly useful for systems with shared SPI buses, allowing other devices to communicate without disrupting ongoing transactions. Connecting the HOLD pin through a pull-up resistor to a GPIO enables controlled operation suspension.

Design Considerations

- Data Integrity and Security: Implement error-checking and security protocols to ensure the integrity and confidentiality of stored data, especially in sensitive applications.

- Environmental Conditions: Account for the operating temperature range and exposure to environmental stressors, ensuring reliable Flash memory operation.

- Firmware Update Mechanisms: Establish a secure and reliable system for firmware updates, including verification and rollback features to handle update failures.

- Power Efficiency: Optimize the circuit for low power consumption, leveraging the Flash memory's energy-saving modes during device inactivity.

- PCB Layout and Signal Integrity: Carefully plan the PCB layout to minimize electromagnetic interference (EMI) and signal degradation, focusing on the integrity of SPI communication lines and power supply decoupling.

Incorporating the S25FS512SAGNFI010 into an embedded system for firmware storage exemplifies leveraging advanced Flash memory technology to enhance system reliability, performance, and security. Addressing the key design considerations outlined above ensures successful integration, capitalizing on the full capabilities of this high-capacity, high-speed NOR Flash memory chip.
