Cypress Semiconductor Corp S25FL256SAGMFI001

Part No.:: S25FL256SAGMFI001

Manufacturer:: Cypress Semiconductor Corp

Package:: 16-SOIC (0.295, 7.50mm Width)

Datasheet:: S25FL256SAGMFI001.pdf

Description:: IC FLASH 256MBIT SPI/QUAD 16SOIC

In Stock:: 491

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

S25FL256SAGMFI001 Specifications

Package/Case:
16-SOIC (0.295, 7.50mm Width)
Packaging:
Bulk,Tube,Tube
Series:
FL-S
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NOR
MemorySize:
256Mb (32M x 8)
MemoryInterface:
SPI - Quad I/O
ClockFrequency:
133 MHz
WriteCycleTime-WordPage:
-
AccessTime:
-
Voltage-Supply:
2.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
