Cypress Semiconductor Corp S25FL127SABMFI101

Part No.:: S25FL127SABMFI101

Manufacturer:: Cypress Semiconductor Corp

Package:: 8-SOIC (0.209, 5.30mm Width)

Datasheet:: S25FL127SABMFI101.pdf

Description:: IC FLASH 128MBIT SPI/QUAD 8SOIC

In Stock:: 3044

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

S25FL127SABMFI101 Specifications

Package/Case:
8-SOIC (0.209, 5.30mm Width)
Packaging:
Bulk,Tube,Tube
Series:
FL-S
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NOR
MemorySize:
128Mb (16M x 8)
MemoryInterface:
SPI - Quad I/O
ClockFrequency:
108 MHz
WriteCycleTime-WordPage:
-
AccessTime:
-
Voltage-Supply:
2.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
