Cypress Semiconductor Corp S25FL064LABMFI013

Part No.:: S25FL064LABMFI013

Manufacturer:: Cypress Semiconductor Corp

Package:: 8-SOIC (0.209, 5.30mm Width)

Datasheet:: S25FL064LABMFI013.pdf

Description:: IC FLASH 64MBIT SPI/QUAD 8SOIC

In Stock:: 2072

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

S25FL064LABMFI013 Specifications

Package/Case:
8-SOIC (0.209, 5.30mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
FL-L
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NOR
MemorySize:
64Mb (8M x 8)
MemoryInterface:
SPI - Quad I/O, QPI
ClockFrequency:
108 MHz
WriteCycleTime-WordPage:
-
AccessTime:
-
Voltage-Supply:
2.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount

S25FL064LABMFI013 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including S25FL064LABMFI013 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for S25FL064LABMFI013 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

S25FL064LABMFI013 information

Views：

S25FL064LABMFI013 Typical application Circuitry

S25FL064LABMFI013

S25FL064LABMFI013 is a Serial NOR Flash memory chip, manufactured by Cypress Semiconductor (now part of Infineon Technologies). It is designed for storage solutions in electronic devices, featuring a Serial Peripheral Interface (SPI) for high-speed data transfer.

Application Scenarios of S25FL064LABMFI013

S25FL064LABMFI013 is used in a variety of applications like embedded systems, digital cameras, gaming devices, network equipment, and other consumer electronics requiring reliable and fast non-volatile storage.

Parameter Features of S25FL064LABMFI013

- Storage Capacity: 64 Megabits.

- SPI Interface: Supports high-speed serial data transfer.

- Low Power Consumption: Efficient for battery-powered devices.

- Fast Read/Write Operations: Suitable for applications needing quick data access.

Specific Circuit Connection Example

Implementing S25FL064LABMFI013 in an embedded system:

1. Power Supply: Attach a steady 2.7V to 3.6V power source to pin 8, which is the Vcc pin. Place a decoupling capacitor near the Vcc pin to stabilize the power supply.

2. Grounding: Connect the GND pin (e.g., pin 4) to the system ground for noise reduction and stable operation.

3. SPI Interface Connections:

- Link the Serial Clock (SCK, pin 6) to the microcontroller's SPI clock line.

- Attach the Serial Input (SI, pin 5) to the microcontroller's Master-Out Slave-In (MOSI) line.

- Connect the Serial Output (SO, pin 2) to the microcontroller's Master-In Slave-Out (MISO) line.

- The Chip Select (CS, pin 1) must be connected to a GPIO pin on the microcontroller in order to activate and deactivate the Flash memory.

4. Write Protection: Use the Write Protect (WP, pin 7) and HOLD (pin 3) pins with the microcontroller's GPIOs to manage the memory write protection and suspend operations.

Design Considerations

- Signal Integrity: Proper PCB layout is crucial for maintaining signal integrity, especially for SPI communication lines.

- Power Supply Design: A stable and clean power supply is essential for reliable memory operations.

- Heat Management: Consider heat dissipation in scenarios of intense read/write cycles.

- EMI/EMC Standards: Compliance with EMI/EMC standards is necessary, especially in sensitive embedded system applications.

Utilizing S25FL064LABMFI013 in embedded systems capitalizes on its high-speed SPI interface and ample storage capacity, making it an excellent choice for efficient and reliable data storage solutions.
