Texas Instruments RM57L843BZWTT

Part No.:: RM57L843BZWTT

Manufacturer:: Texas Instruments

Package:: 337-LFBGA

Datasheet:: RM57L843BZWTT.pdf

Description:: IC MCU 16/32B 4MB FLASH 337NFBGA

In Stock:: 3156

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

RM57L843BZWTT Specifications

Package/Case:
337-LFBGA
Packaging:
Tray
Series:
Hercules™ RM4 ARM® Cortex®-R4, Functional Safety (FuSa)
RoHS:
RoHS
Speed:
330MHz
RAM Size:
512K x 8
Core Size:
16/32-Bit
EEPROM Size:
128K x 8
Part Status:
Active
Peripherals:
DMA, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, Ethernet, I²C, LINbus, MibSPI, SCI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
145
Core Processor:
ARM® Cortex®-R5F
Data Converters:
A/D 57x10/12b
Oscillator Type:
External
Program Memory Size:
4MB (4M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 105°C (TA)
