Name: R5F21258SNFP#V2
Brand: Renesas Electronics America Inc
SKU: R5F21258SNFP#V2
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Renesas Electronics America Inc R5F21258SNFP#V2

Part No.:: R5F21258SNFP#V2

Manufacturer:: Renesas Electronics America Inc

Package:: 52-LQFP

Datasheet:: R5F21258SNFP#V2.pdf

Description:: IC MCU 16BIT 64KB FLASH 52LQFP

In Stock:: 350

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

R5F21258SNFP#V2 Specifications

Package/Case:
52-LQFP
Packaging:
Tray
Series:
R8C/2x/25
RoHS:
RoHS
Speed:
20MHz
RAM Size:
3K x 8
Core Size:
16-Bit
EEPROM Size:
-
Part Status:
Not For New Designs
Peripherals:
POR, Voltage Detect, WDT
Connectivity:
I²C, LINbus, SIO, SSU, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
41
Core Processor:
R8C
Data Converters:
A/D 12x10b
Oscillator Type:
Internal
Program Memory Size:
64KB (64K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-20°C ~ 85°C (TA)
