Renesas Electronics America Inc R5F10BGGCLFB#15

Part No.:: R5F10BGGCLFB#15

Manufacturer:: Renesas Electronics America Inc

Package:: 48-LQFP

Datasheet:

Description:: IC MCU 16BIT 128KB FLASH 48LFQFP

In Stock:: 2572

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

R5F10BGGCLFB#15 Specifications

Package/Case:
48-LQFP
Packaging:
Tape & Reel (TR)
Series:
RL78/F13
RoHS:
RoHS
Speed:
32MHz
RAM Size:
8K x 8
Core Size:
16-Bit
EEPROM Size:
4K x 8
Part Status:
Active
Peripherals:
LVD, POR, PWM, WDT
Connectivity:
CANbus, CSI, I²C, LINbus, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
38
Core Processor:
RL78
Data Converters:
A/D 17x10b SAR
Oscillator Type:
Internal
Program Memory Size:
128KB (128K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 105°C (TA)
