Renesas Electronics America Inc R5F100FEAFP#30

Part No.:: R5F100FEAFP#30

Manufacturer:: Renesas Electronics America Inc

Package:: 44-LQFP

Datasheet:: R5F100FEAFP#30.pdf

Description:: IC MCU 16BIT 64KB FLASH 44LQFP

In Stock:: 475

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

R5F100FEAFP#30 Specifications

Package/Case:
44-LQFP
Packaging:
Tray
Series:
RL78/G13
RoHS:
RoHS
Speed:
32MHz
RAM Size:
4K x 8
Core Size:
16-Bit
EEPROM Size:
4K x 8
Part Status:
Active
Peripherals:
DMA, LVD, POR, PWM, WDT
Connectivity:
CSI, I²C, LINbus, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
31
Core Processor:
RL78
Data Converters:
A/D 10x8/10b
Oscillator Type:
Internal
Program Memory Size:
64KB (64K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
