Renesas Electronics America Inc PS2801-4-F3-A

Part No.:: PS2801-4-F3-A

Manufacturer:: Renesas Electronics America Inc

Package:: 16-SOIC (0.173, 4.40mm Width)

Datasheet:: PS2801-4-F3-A.pdf

Description:: OPTOISO 2.5KV 4CH TRANS 16-SSOP

In Stock:: 3079

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PS2801-4-F3-A Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Not For New Designs
NumberofChannels:
4
Voltage-Isolation:
2500Vrms
CurrentTransferRatio(Min):
80% @ 5mA
CurrentTransferRatio(Max):
600% @ 5mA
TurnOn/TurnOffTime(Typ):
6µs, 5µs
Rise/FallTime(Typ):
3µs, 5µs
InputType:
DC
OutputType:
Transistor
Voltage-Output(Max):
80V
Current-Output/Channel:
50mA
Voltage-Forward(Vf)(Typ):
1.1V
Current-DCForward(If)(Max):
50 mA
VceSaturation(Max):
300mV
OperatingTemperature:
-55°C ~ 100°C
MountingType:
Surface Mount
