Nexperia USA Inc. PMBT3906YS,115

Part No.:: PMBT3906YS,115

Manufacturer:: Nexperia USA Inc.

Package:: 6-TSSOP, SC-88, SOT-363

Datasheet:: PMBT3906YS,115.pdf

Description:: TRANS 2PNP 40V 0.2A 6TSSOP

In Stock:: 3882

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PMBT3906YS,115 Specifications

Packaging:
Tape & Reel (TR)
Series:
Automotive, AEC-Q101
ProductStatus:
Active
TransistorType:
2 PNP (Dual)
Current-Collector(Ic)(Max):
200mA
Voltage-CollectorEmitterBreakdown(Max):
40V
VceSaturation(Max)@IbIc:
400mV @ 5mA, 50mA
Current-CollectorCutoff(Max):
50nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
100 @ 10mA, 1V
Power-Max:
350mW
Frequency-Transition:
250MHz
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
