Microchip Technology PIC32MZ2048EFH064-I/PT

Part No.:: PIC32MZ2048EFH064-I/PT

Manufacturer:: Microchip Technology

Package:: 64-TQFP

Datasheet:: PIC32MZ2048EFH064-I/PT.pdf

Description:: IC MCU 32BIT 2MB FLASH 64TQFP

In Stock:: 3832

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PIC32MZ2048EFH064-I/PT Specifications

Package/Case:
64-TQFP
Packaging:
Tray
Series:
PIC® 32MZ
RoHS:
RoHS
Speed:
200MHz
RAM Size:
512K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT
Connectivity:
CANbus, Ethernet, I²C, PMP, SPI, SQI, UART/USART, USB OTG
Mounting Type:
Surface Mount
Number of I/O:
46
Core Processor:
MIPS32® M-Class
Data Converters:
A/D 24x12b
Oscillator Type:
Internal
Program Memory Size:
2MB (2M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
