Name: PIC32MX795F512H-80I/PT
Brand: Microchip Technology
SKU: PIC32MX795F512H-80I/PT
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Microchip Technology PIC32MX795F512H-80I/PT

Part No.:: PIC32MX795F512H-80I/PT

Manufacturer:: Microchip Technology

Package:: 64-TQFP

Datasheet:: PIC32MX795F512H-80I/PT.pdf

Description:: IC MCU 32BIT 512KB FLASH 64TQFP

In Stock:: 2203

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PIC32MX795F512H-80I/PT Specifications

Package/Case:
64-TQFP
Packaging:
Tray
Series:
PIC® 32MX
RoHS:
RoHS
Speed:
80MHz
RAM Size:
128K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, POR, PWM, WDT
Connectivity:
CANbus, Ethernet, I²C, SPI, UART/USART, USB OTG
Mounting Type:
Surface Mount
Number of I/O:
53
Core Processor:
MIPS32® M4K™
Data Converters:
A/D 16x10b
Oscillator Type:
Internal
Program Memory Size:
512KB (512K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
