Microchip Technology PIC24EP512GU810-I/PF

Part No.:: PIC24EP512GU810-I/PF

Manufacturer:: Microchip Technology

Package:: 100-TQFP

Datasheet:: PIC24EP512GU810-I/PF.pdf

Description:: IC MCU 16BIT 512KB FLASH 100TQFP

In Stock:: 2511

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PIC24EP512GU810-I/PF Specifications

Package/Case:
100-TQFP
Packaging:
Tray
Series:
PIC® 24EP
RoHS:
RoHS
Speed:
60 MIPs
RAM Size:
24K x 16
Core Size:
16-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, POR, PWM, WDT
Connectivity:
CANbus, I²C, IrDA, LINbus, SPI, UART/USART, USB OTG
Mounting Type:
Surface Mount
Number of I/O:
83
Core Processor:
PIC
Data Converters:
A/D 32x10b/12b
Oscillator Type:
Internal
Program Memory Size:
512KB (170K x 24)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
