Microchip Technology PIC18LF6722-I/PT

Part No.:: PIC18LF6722-I/PT

Manufacturer:: Microchip Technology

Package:: 64-TQFP

Datasheet:: PIC18LF6722-I/PT.pdf

Description:: IC MCU 8BIT 128KB FLASH 64TQFP

In Stock:: 3581

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PIC18LF6722-I/PT Specifications

Package/Case:
64-TQFP
Packaging:
Tray
Series:
PIC® 18F
RoHS:
RoHS
Speed:
40MHz
RAM Size:
3.8K x 8
Core Size:
8-Bit
EEPROM Size:
1K x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Connectivity:
I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
54
Core Processor:
PIC
Data Converters:
A/D 12x10b
Oscillator Type:
Internal
Program Memory Size:
128KB (64K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
