Microchip Technology PIC18F66K80-I/PT

Part No.:: PIC18F66K80-I/PT

Manufacturer:: Microchip Technology

Package:: 64-TQFP

Datasheet:: PIC18F66K80-I/PT.pdf

Description:: IC MCU 8BIT 64KB FLASH 64TQFP

In Stock:: 3340

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PIC18F66K80-I/PT Specifications

Package/Case:
64-TQFP
Packaging:
Tray
Series:
PIC® XLP™ 18K
RoHS:
RoHS
Speed:
64MHz
RAM Size:
3.6K x 8
Core Size:
8-Bit
EEPROM Size:
1K x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, LVD, POR, PWM, WDT
Connectivity:
ECANbus, I²C, LINbus, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
54
Core Processor:
PIC
Data Converters:
A/D 11x12b
Oscillator Type:
Internal
Program Memory Size:
64KB (32K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
