Name: PIC18F25K80-E/SS
Brand: Microchip Technology
SKU: PIC18F25K80-E/SS
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Microchip Technology PIC18F25K80-E/SS

Part No.:: PIC18F25K80-E/SS

Manufacturer:: Microchip Technology

Package:: 28-SSOP (0.209", 5.30mm Width)

Datasheet:: PIC18F25K80-E/SS.pdf

Description:: IC MCU 8BIT 32KB FLASH 28SSOP

In Stock:: 3023

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PIC18F25K80-E/SS Specifications

Package/Case:
28-SSOP (0.209", 5.30mm Width)
Packaging:
Tube
Series:
PIC® XLP™ 18K
RoHS:
RoHS
Speed:
64MHz
RAM Size:
3.6K x 8
Core Size:
8-Bit
EEPROM Size:
1K x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, LVD, POR, PWM, WDT
Connectivity:
ECANbus, I²C, LINbus, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
24
Core Processor:
PIC
Data Converters:
A/D 8x12b
Oscillator Type:
Internal
Program Memory Size:
32KB (16K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TA)
