Microchip Technology PIC17C756A-33I/PT

Part No.:: PIC17C756A-33I/PT

Manufacturer:: Microchip Technology

Package:: 64-TQFP

Datasheet:: PIC17C756A-33I/PT.pdf

Description:: IC MCU 8BIT 32KB OTP 64TQFP

In Stock:: 3489

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PIC17C756A-33I/PT Specifications

Package/Case:
64-TQFP
Packaging:
Tray
Series:
PIC® 17C
RoHS:
RoHS
Speed:
33MHz
RAM Size:
902 x 8
Core Size:
8-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
50
Core Processor:
PIC
Data Converters:
A/D 12x10b
Oscillator Type:
External
Program Memory Size:
32KB (16K x 16)
Program Memory Type:
OTP
Operating Temperature:
-40°C ~ 85°C (TA)
