Microchip Technology PIC16F785T-I/SS

Part No.:: PIC16F785T-I/SS

Manufacturer:: Microchip Technology

Package:: 20-SSOP (0.209", 5.30mm Width)

Datasheet:: PIC16F785T-I/SS.pdf

Description:: IC MCU 8BIT 3.5KB FLASH 20SSOP

In Stock:: 3984

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PIC16F785T-I/SS Specifications

Package/Case:
20-SSOP (0.209", 5.30mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
PIC® 16F
RoHS:
RoHS
Speed:
20MHz
RAM Size:
128 x 8
Core Size:
8-Bit
EEPROM Size:
256 x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
-
Mounting Type:
Surface Mount
Number of I/O:
17
Core Processor:
PIC
Data Converters:
A/D 14x10b
Oscillator Type:
Internal
Program Memory Size:
3.5KB (2K x 14)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
