Name: PIC16F77-I/PT
Brand: Microchip Technology
SKU: PIC16F77-I/PT
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Microchip Technology PIC16F77-I/PT

Part No.:: PIC16F77-I/PT

Manufacturer:: Microchip Technology

Package:: 44-TQFP

Datasheet:: PIC16F77-I/PT.pdf

Description:: IC MCU 8BIT 14KB FLASH 44TQFP

In Stock:: 2688

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PIC16F77-I/PT Specifications

Package/Case:
44-TQFP
Packaging:
Tray
Series:
PIC® 16F
RoHS:
RoHS
Speed:
20MHz
RAM Size:
368 x 8
Core Size:
8-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
33
Core Processor:
PIC
Data Converters:
A/D 8x8b
Oscillator Type:
External
Program Memory Size:
14KB (8K x 14)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

PIC16F77-I/PT this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including PIC16F77-I/PT price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for PIC16F77-I/PT to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

PIC16F77-I/PT information

Views：

PIC16F77-I/PT Typical application Circuitry

The PIC16F77-I/PT is a type of microcontroller unit (MCU) from the PIC family, produced by Microchip Technology. This highly integrated device is primarily designed to serve in embedded systems.

Various application areas for the PIC16F77-I/PT can include:

- Home automation systems

- Motor control systems

- Industrial measurement and control systems

- Sensor interfacing and data acquisition systems

There are several essential features of the PIC16F77-I/PT:

- It runs at a voltage range from 4.0V to 5.5V.

- It consists of 14KB of flash memory.

- It includes 368 bytes of SRAM and 256 bytes of EEPROM.

- It offers 33 input/output (I/O) pins.

- It supports multiple peripherals such as ADC, timers, and interfaces including SPI, I2C, and UART.

Let's take a look at a typical application for the PIC16F77-I/PT, such as a motor control system:

1. Power Provision: The VDD and VSS pins need to connect to the power source and ground, respectively, ensuring the supply voltage remains within the approved range.

2. Motor Interface: An H-bridge motor driver can be connected to some GPIO pins (such as RB0-RB3), which manage the motor's direction and speed.

3. Speed Sensor: A rotary encoder connected to an interrupt pin (like RB0/INT) can monitor the motor's speed.

4. User Interface: A couple of push buttons for user input can be connected to other GPIO pins (such as RA0 and RA1), controlling motor start/stop and speed adjustment.

5. Reset: Attach the MCLR pin to a reset button for resetting the MCU whenever needed.

Several crucial considerations when designing a circuit with the PIC16F77-I/PT include:

- Power Supply Stability: Make sure the power supply is steady and clean. Noise can cause erratic operation, which can be mitigated using decoupling capacitors.

- I/O Pin Limits: I/O pins have voltage and current limits. Exceeding these parameters might damage the MCU.

- Code Size: Confirm your code fits within the available memory of the MCU. If it's larger, you might need to opt for an MCU with more memory.

In summary, the PIC16F77-I/PT is a powerful, feature-rich microcontroller suitable for a vast range of applications. It provides robust capabilities that can meet the demands of complex embedded system designs.
