Texas Instruments PCM5121PWR

Part No.:: PCM5121PWR

Manufacturer:: Texas Instruments

Package:: 28-TSSOP (0.173, 4.40mm Width)

Datasheet:: PCM5121PWR.pdf

Description:: IC DAC 16/24/32BIT 384K 28TSSOP

In Stock:: 3128

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PCM5121PWR Specifications

Package/Case:
28-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
DirectPath™
ProductStatus:
Active
Type:
DAC, Audio
NumberofChannels:
2
Resolution(Bits):
16 b, 24 b, 32 b
SamplingRate(PerSecond):
384k
DataInterface:
PCM
VoltageSupplySource:
Analog and Digital
Voltage-Supply:
1.65V ~ 3.46V
OperatingTemperature:
-25°C ~ 85°C
MountingType:
Surface Mount
