NXP USA Inc. P87LPC769HD,518

Part No.:: P87LPC769HD,518

Manufacturer:: NXP USA Inc.

Package:: 20-SOIC (0.295", 7.50mm Width)

Datasheet:: P87LPC769HD,518.pdf

Description:: IC MCU 8BIT 4KB OTP 20SO

In Stock:: 3871

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

P87LPC769HD,518 Specifications

Package/Case:
20-SOIC (0.295", 7.50mm Width)
Packaging:
Tape & Reel (TR)
Series:
LPC700
RoHS:
RoHS
Speed:
20MHz
RAM Size:
128 x 8
Core Size:
8-Bit
EEPROM Size:
-
Part Status:
Obsolete
Peripherals:
Brown-out Detect/Reset, LED, POR, WDT
Connectivity:
I²C, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
18
Core Processor:
8051
Data Converters:
A/D 4x8b; D/A 2x8b
Oscillator Type:
Internal
Program Memory Size:
4KB (4K x 8)
Program Memory Type:
OTP
Operating Temperature:
-40°C ~ 125°C (TA)

P87LPC769HD,518 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including P87LPC769HD,518 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for P87LPC769HD,518 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
