NXP USA Inc. P80C552EFA/08,518

Part No.:: P80C552EFA/08,518

Manufacturer:: NXP USA Inc.

Package:: 68-LCC (J-Lead)

Datasheet:: P80C552EFA/08,518.pdf

Description:: IC MCU 8BIT ROMLESS 68PLCC

In Stock:: 3176

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

P80C552EFA/08,518 Specifications

Package/Case:
68-LCC (J-Lead)
Packaging:
Tape & Reel (TR)
Series:
80C
RoHS:
RoHS
Speed:
16MHz
RAM Size:
256 x 8
Core Size:
8-Bit
EEPROM Size:
-
Part Status:
Obsolete
Peripherals:
POR, PWM, WDT
Connectivity:
EBI/EMI, I²C, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
40
Core Processor:
8051
Data Converters:
A/D 8x10b
Oscillator Type:
Internal
Program Memory Size:
-
Program Memory Type:
ROMless
Operating Temperature:
-40°C ~ 85°C (TA)
