NXP USA Inc. P2040NSN7MMC

Part No.:: P2040NSN7MMC

Manufacturer:: NXP USA Inc.

Package:: 780-BFBGA, FCBGA

Datasheet:: P2040NSN7MMC.pdf

Description:: IC MPU Q OR IQ 1.2GHZ 780FCBGA

In Stock:: 2882

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

P2040NSN7MMC Specifications

Package/Case:
780-BFBGA, FCBGA
Packaging:
Tray
Series:
QorIQ P2
Product Status:
Obsolete
Core Processor:
PowerPC e500mc
Numberof Cores/BusWidth:
4 Core, 32-Bit
Speed:
1.2GHz
Co-Processors/DSP:
-
RAM Controllers:
DDR3, DDR3L
Graphics Acceleration:
No
Display & Interface Controllers:
-
Ethernet:
10/100/1000Mbps (5)
SATA:
SATA 3Gbps (2)
USB:
USB 2.0 + PHY (2)
Voltage-I/O:
1.0V, 1.35V, 1.5V, 1.8V, 2.5V, 3.3V
Operating Temperature:
0°C ~ 105°C (TA)
Grade:
-
Qualification:
Security Features:
