NXP USA Inc. P2020NSN2MFC

Part No.:: P2020NSN2MFC

Manufacturer:: NXP USA Inc.

Package:: 689-BBGA Exposed Pad

Datasheet:: P2020NSN2MFC.pdf

Description:: IC MPU Q OR IQ 1.2GHZ 689TEBGA

In Stock:: 3049

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

P2020NSN2MFC Specifications

Package/Case:
689-BBGA Exposed Pad
Packaging:
Tray
Series:
QorIQ P2
Product Status:
Obsolete
Core Processor:
PowerPC e500v2
Numberof Cores/BusWidth:
2 Core, 32-Bit
Speed:
1.2GHz
Co-Processors/DSP:
-
RAM Controllers:
DDR2, DDR3
Graphics Acceleration:
No
Display & Interface Controllers:
-
Ethernet:
10/100/1000Mbps (3)
SATA:
-
USB:
USB 2.0 + PHY (2)
Voltage-I/O:
-
Operating Temperature:
0°C ~ 125°C (TA)
Grade:
-
Qualification:
Security Features:
