NXP USA Inc. P2020NSE2KFC

Part No.:: P2020NSE2KFC

Manufacturer:: NXP USA Inc.

Package:: 689-BBGA Exposed Pad

Datasheet:: P2020NSE2KFC.pdf

Description:: IC MPU Q OR IQ 1.2GHZ 689TEBGA

In Stock:: 2770

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

P2020NSE2KFC Specifications

Package/Case:
689-BBGA Exposed Pad
Packaging:
Tray
Series:
QorIQ P2
Product Status:
Obsolete
Core Processor:
PowerPC e500v2
Numberof Cores/BusWidth:
2 Core, 32-Bit
Speed:
1.2GHz
Co-Processors/DSP:
Security; SEC 3.3
RAM Controllers:
DDR2, DDR3
Graphics Acceleration:
No
Display & Interface Controllers:
-
Ethernet:
10/100/1000Mbps (3)
SATA:
-
USB:
USB 2.0 + PHY (2)
Voltage-I/O:
-
Operating Temperature:
0°C ~ 125°C (TA)
Grade:
Cryptography, Random Number Generator
Qualification:
Security Features:

P2020NSE2KFC this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including P2020NSE2KFC price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for P2020NSE2KFC to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

P2020NSE2KFC information

Views：

P2020NSE2KFC Typical application Circuitry

P2020NSE2KFC

The P2020NSE2KFC is a high-performance integrated circuit designed for a wide range of embedded applications. This processor is part of the PowerQUICC family, known for its excellent processing power, energy efficiency, and integrated communication capabilities.

Application Scenarios

Network Routers: The P2020NSE2KFC is particularly adept for use in network routers, where it can manage data traffic efficiently, support various networking protocols, and facilitate secure data communication.

Parameter Features

- Dual-Core Processor: The P2020NSE2KFC features a dual-core design, enabling it to execute multiple processes simultaneously with high efficiency.

- Energy Efficiency: Tailored for applications where power efficiency is paramount, this chip incorporates advanced power management features.

- Comprehensive Connectivity: Offering a wide range of connectivity options, including Gigabit Ethernet, PCI Express, and USB, the P2020NSE2KFC ensures flexible integration into various system designs.

Detailed Circuit Connection: Network Router

Ethernet Interface Configuration:

- Gigabit Ethernet Ports: The P2020NSE2KFC's Ethernet pins are connected to Ethernet PHY devices and then to RJ45 connectors with integrated magnetics. This setup is essential for establishing high-speed network connections. Proper impedance matching and signal routing are necessary to maintain signal integrity.

Power Supply Arrangement:

- Voltage Regulation: The power supply pins of the P2020NSE2KFC require connection to a stable and regulated power source, with specific attention paid to providing clean power. This may involve the use of linear regulators, switching regulators, or power management ICs to achieve the desired voltage levels while minimizing noise.

System Clock Sourcing:

- External Clock Source: An accurate and stable external clock source is connected to the P2020NSE2KFC to ensure precise timing for all operations. The selection of the clock source and its integration into the circuit is critical for the overall performance and reliability of the router.

Memory Interface Setup:

- RAM Connection: The P2020NSE2KFC is interfaced with RAM modules to provide necessary working memory for processing tasks. The memory interface pins must be accurately connected, and considerations for speed, capacity, and access times are crucial for optimal performance.

Peripheral and Expansion Slot Integration:

- PCI Express Slots: The PCI Express (PCIe) lanes of the P2020NSE2KFC are routed to expansion slots or directly to PCIe devices, allowing for the addition of various peripherals such as additional network interfaces or storage controllers. The layout and impedance control are key factors to ensure high-speed data transfer without signal degradation.

Design Considerations

- Thermal Management: Implementing effective thermal management techniques, including heat sinks and airflow management, is crucial to maintain the P2020NSE2KFC within its operational temperature range, ensuring reliability and longevity.

- Signal Integrity: Careful PCB layout design to maintain signal integrity, especially for high-speed signals like Ethernet and PCIe, is critical. Techniques such as differential signaling, controlled impedance traces, and proper grounding can mitigate signal degradation and cross-talk.

- Electromagnetic Compatibility (EMC): Ensuring the design complies with EMC regulations involves careful routing of signal and power traces, as well as incorporating filtering and shielding methods to reduce electromagnetic emissions and susceptibility.

- Power Stability: Maintaining stable power supply to the P2020NSE2KFC and its peripherals is essential. This involves the use of decoupling capacitors close to the chip pins and considering power distribution network (PDN) design to avoid voltage drops and fluctuations.

- Reliability and Redundancy: For network routers, reliability is critical. Designing with redundancy in mind, such as dual power supplies or failover network interfaces, can ensure continuous operation even in the event of component failure.

In summary, the P2020NSE2KFC is a powerful and versatile processor suitable for demanding applications like network routers. By leveraging its processing capabilities, connectivity options, and energy efficiency, and addressing design considerations such as thermal management, signal integrity, and power stability, developers can create advanced, reliable, and efficient network routing solutions.
