OmniVision Technologies Inc OV02715-A68A-RE

Part No.:: OV02715-A68A-RE

Manufacturer:: OmniVision Technologies Inc

Package:: 68-CSP3

Datasheet:

Description:: CAMERA CHIP SENSOR

In Stock:: 3350

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

OV02715-A68A-RE Specifications

Packaging:
Tray
Series:
OmniPixel3-HS™
ProductStatus:
Obsolete
Type:
CMOS with Processor
PixelSize:
3µm x 3µm
ActivePixelArray:
1920H x 1080V
FramesperSecond:
30
Voltage-Supply:
1.425V ~ 1.575V
