Name: NX3L4051HRZ
Brand: NXP USA Inc.
SKU: NX3L4051HRZ
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

NXP USA Inc. NX3L4051HRZ

Part No.:: NX3L4051HRZ

Manufacturer:: NXP USA Inc.

Package:: 16-XFQFN Exposed Pad

Datasheet:

Description:: IC ANALOG SWITCH 8CH SGL HXQFN16

In Stock:: 3316

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NX3L4051HRZ Specifications

Package/Case:
16-XFQFN Exposed Pad
Packaging:
Tape & Reel (TR)
Series:
Automotive, AEC-Q100
ProductStatus:
Active
SwitchCircuit:
-
Multiplexer/DemultiplexerCircuit:
8:1
NumberofCircuits:
1
On-StateResistance(Max):
900mOhm
Channel-to-ChannelMatching(ΔRon):
70mOhm
Voltage-SupplySingle(V+):
1.4V ~ 4.3V
Voltage-SupplyDual(V±):
1.4V ~ 4.3V
SwitchTime(TonToff)(Max):
45ns, 25ns
-3dbBandwidth:
15MHz
ChargeInjection:
15pC
ChannelCapacitance(CS(off)CD(off)):
35pF
Current-Leakage(IS(off))(Max):
10nA
Crosstalk:
-90dB @ 100kHz
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
