Name: NLAS2750MUTAG
Brand: ON Semiconductor
SKU: NLAS2750MUTAG
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

ON Semiconductor NLAS2750MUTAG

Part No.:: NLAS2750MUTAG

Manufacturer:: ON Semiconductor

Package:: 10-UFQFN

Datasheet:: NLAS2750MUTAG.pdf

Description:: IC SWITCH DUAL SPDT 10UQFN

In Stock:: 2411

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NLAS2750MUTAG Specifications

Package/Case:
10-UFQFN
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Obsolete
SwitchCircuit:
SPDT
Multiplexer/DemultiplexerCircuit:
2:1
NumberofCircuits:
2
On-StateResistance(Max):
1.3Ohm
Channel-to-ChannelMatching(ΔRon):
100mOhm
Voltage-SupplySingle(V+):
1.8V ~ 5V
Voltage-SupplyDual(V±):
-
SwitchTime(TonToff)(Max):
150ns, 130ns
-3dbBandwidth:
44MHz
ChargeInjection:
60pC
ChannelCapacitance(CS(off)CD(off)):
5pF
Current-Leakage(IS(off))(Max):
250nA
Crosstalk:
-60dB @ 300kHz
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
