ON Semiconductor NL37WZ17USG

Part No.:: NL37WZ17USG

Manufacturer:: ON Semiconductor

Package:: 8-VFSOP (0.091, 2.30mm Width)

Datasheet:: NL37WZ17USG.pdf

Description:: IC BUFFER NON-INVERT 5.5V US8

In Stock:: 2347

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NL37WZ17USG Specifications

Package/Case:
8-VFSOP (0.091, 2.30mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
37WZ
ProductStatus:
Obsolete
LogicType:
Buffer, Non-Inverting
NumberofElements:
3
NumberofBitsperElement:
1
InputType:
Schmitt Trigger
OutputType:
Push-Pull
Current-OutputHighLow:
32mA, 32mA
Voltage-Supply:
2.3V ~ 5.5V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
