Name: NJU39610FM2
Brand: Nisshinbo Micro Devices Inc.
SKU: NJU39610FM2
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Nisshinbo Micro Devices Inc. NJU39610FM2

Part No.:: NJU39610FM2

Manufacturer:: Nisshinbo Micro Devices Inc.

Package:: 28-LCC (J-Lead)

Datasheet:: NJU39610FM2.pdf

Description:: IC MOTOR DRIVER BIPOLAR 28PLCC

In Stock:: 3006

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NJU39610FM2 Specifications

Packaging:
Tube
Series:
-
ProductStatus:
Obsolete
MotorType-Stepper:
Bipolar
MotorType-ACDC:
-
Function:
Controller - Commutation, Direction Management
OutputConfiguration:
Pre-Driver - Half Bridge (4)
Interface:
Parallel
Technology:
-
StepResolution:
>256 Microsteps
Applications:
General Purpose
Current-Output:
-
Voltage-Supply:
4.75V ~ 5.25V
Voltage-Load:
-
OperatingTemperature:
-20°C ~ 85°C (TA)
MountingType:
Surface Mount
