Name: NCV70624DW010R2G
Brand: ON Semiconductor
SKU: NCV70624DW010R2G
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

ON Semiconductor NCV70624DW010R2G

Part No.:: NCV70624DW010R2G

Manufacturer:: ON Semiconductor

Package:: 20-SOIC (0.295, 7.50mm Width)

Datasheet:: NCV70624DW010R2G.pdf

Description:: IC MTR DRV BIPOLR 6.5-29V 20SOIC

In Stock:: 2876

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NCV70624DW010R2G Specifications

Packaging:
Tape & Reel (TR),Bulk
Series:
-
ProductStatus:
Obsolete
MotorType-Stepper:
Bipolar
MotorType-ACDC:
-
Function:
Driver - Fully Integrated, Control and Power Stage
OutputConfiguration:
Half Bridge (4)
Interface:
I²C
Technology:
Power MOSFET
StepResolution:
1/2, 1/4, 1/8, 1/16
Applications:
General Purpose
Current-Output:
-
Voltage-Supply:
6.5V ~ 29V
Voltage-Load:
6.5V ~ 29V
OperatingTemperature:
-40°C ~ 165°C (TJ)
MountingType:
Surface Mount
