ON Semiconductor NC7SB3157P6X

Part No.:: NC7SB3157P6X

Manufacturer:: ON Semiconductor

Package:: 6-TSSOP, SC-88, SOT-363

Datasheet:: NC7SB3157P6X.pdf

Description:: IC SWITCH SPDT SC70-6

In Stock:: 3597

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NC7SB3157P6X Specifications

Package/Case:
6-TSSOP, SC-88, SOT-363
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
SwitchCircuit:
SPDT
Multiplexer/DemultiplexerCircuit:
2:1
NumberofCircuits:
1
On-StateResistance(Max):
15Ohm
Channel-to-ChannelMatching(ΔRon):
150mOhm
Voltage-SupplySingle(V+):
1.65V ~ 5.5V
Voltage-SupplyDual(V±):
-
SwitchTime(TonToff)(Max):
5.2ns, 3.5ns
-3dbBandwidth:
250MHz
ChargeInjection:
7pC
ChannelCapacitance(CS(off)CD(off)):
6.5pF
Current-Leakage(IS(off))(Max):
100nA
Crosstalk:
-54dB @ 10MHz
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
