Nuvoton Technology Corporation of America N76E003AT20

Part No.:: N76E003AT20

Manufacturer:: Nuvoton Technology Corporation of America

Package:: 20-TSSOP (0.173", 4.40mm Width)

Datasheet:: N76E003AT20.pdf

Description:: IC MCU 8BIT 18KB FLASH 20TSSOP

In Stock:: 3235

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

N76E003AT20 Specifications

Package/Case:
20-TSSOP (0.173", 4.40mm Width)
Packaging:
Tube
Series:
N76
RoHS:
RoHS
Speed:
16MHz
RAM Size:
1K x 8
Core Size:
8-Bit
EEPROM Size:
4K x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, I²S, POR, PWM, WDT
Connectivity:
I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
18
Core Processor:
8051
Data Converters:
A/D 8x12b
Oscillator Type:
Internal
Program Memory Size:
18KB (18K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 105°C (TA)
